- Sealed for moisture and dust resistance
- Hard-anodized cylinder bore for reduced friction
- Teflon-impregnated carbon fiber piston seal for maximum trouble-free life
- Anodized mounting bracket dissipates motor heat and allows compressor to be repositioned 180 degrees on vehicle mounted models
- Quality components for quiet operation and extra long life
- Constructed entirely of lightweight, high-strength engineering-grade materials
- Over-pressure safety valve equipped
- Motor is internally thermal protected against extreme temperature damage
- Heavy-duty MAXI fuse equipped for professional in-line circuit protection
- On-board model available a 12V configuration
Specifications
| Model / Description | CKMP12 HIGH OUTPUT PORTABLE |
| Supply Voltage | 12V |
| Current Draw (No-Load) | 14.2A |
| Air Flow (No-Load) | 87.2lpm @0kPa // 3.08CFM @0PSI |
| Current Draw (Under-Load) | 25.2A |
| Air Flow (Under-Load) | 65.9lpm @200kPa // 2.34CFM @29PSI |
| Duty Cycle (on time / off time) @22°C | 50% 30/30 |
| Weight | 6.6kg |
| Dimensions (mm) | H208 x L440 x W238 |
