LED Autolamps Awning Light Silver 12V 260mm | Camping Lights

SKU: 23260
$49.00

Ideal for caravans, RVs, and trailers requiring exterior lighting solutions operating on 12V systems.

1 x LED Autolamps 23 Series Awning Light

Mounting screws

User instructions


Length: 260mm

Width: 23mm

Depth: 24mm

Designed for caravans and RVs, the 23 Series Awning Light offers a sleek silver finish with high brightness LEDs, a low current draw, and is 12V only.

[{"variant_id":"33219022422125" , "metafield_value":""}]

LED Autolamps Awning Light Silver 12V 260mm | Camping Lights

$49.00
Description

The 23 Series Awning Light from LED Autolamps is a top choice for camping and awning applications, featuring a sleek silver finish. This exterior-grade LED lamp is easy to install and operates at 12V or 24V with low current draw.

It offers bright, warm white light with a 60° spread, available in two sizes: 260mm with 18 LEDs producing 80 Lux at 1 meter, and 443mm with 36 LEDs producing 165 Lux at 1 meter.

The light is rated IP67 for full dust and water protection and comes with a 3-year warranty. Installation is simple—just remove the end caps, mount on a flat surface with supplied screws, then refit the end caps.

FEATURES

Silver anodised aluminium housing

60° light spread

3000K warm white light

Low profile design

Fully encapsulated circuitry

Compliant with Australian road regulations (ADR/ECE approved)

FAQ's

Q: Is this light waterproof?
A: Yes, rated IP67, fully sealed against dust and water.

Q: What voltage does it support?
A: 12V DC only.

Q: How many LEDs does it have?
A: 18 high-intensity LEDs.

Specifications

Voltage: 12V DC

Current Draw: 0.38A @ 13.8V

Ingress Protection: IP67

Lumens: 240lm (effective), 320lm (raw)

Illuminance @1m: 80lx

LED Quantity:
18

Cable Length: 20cm

Housing: Aluminium

Bracket: ABS

Data Sheet

Installation Information

Remove end caps and fit onto a flat surface with screws supplied, then refit end caps.

Warranty Information

Covered by a 3-year manufacturer warranty against defects in materials and workmanship.

PICKUP OR SHIPPING

Pickup available in-store at Elevate Automotive. Shipping Australia-wide and internationally.
