A blue Amptron BluEdge 12V 200Ah lithium iron phosphate battery with Bluetooth and RS485 communication interfaces.
A blue Amptron BluEdge 12V 200Ah lithium iron phosphate battery with Bluetooth and RS485 communication interfaces.

Bluedge Slimline 12V 200Ah / 200A Cont. Discharge LiFePO4 Battery Amptron

SKU: AT-LFP-12-200-BTC-DV10
$1,709.05 $1,799.00
  • VEHICLE
  • INCLUDED
  • DIMENSIONS

Suitable for a wide range of 12V systems, including RVs, caravans, marine vessels, solar energy storage, and industrial applications requiring dependable deep cycle power.


One Amptron BluEdge Slimline 12V 200Ah LiFePO₄ Battery

Length – 430mm

Width – 120mm

Height – 270mm

Weight – 23kg

 [{"variant_id":"47691244339473" , "metafield_value":""}]

Bluedge Slimline 12V 200Ah / 200A Cont. Discharge LiFePO4 Battery Amptron

$1,709.05 $1,799.00
Description

The Amptron BluEdge Slimline 12V 200Ah LiFePO₄ Battery is a high-performance, compact power solution ideal for RVs, marine systems, off-grid setups, and industrial use. With a 200A continuous and 400A peak discharge (3 sec), it’s built for demanding applications where space is limited.

The slimline design supports flexible installation—including on its side—without compromising performance. Built with aluminum-encased prismatic cells, solid busbars, and a reinforced frame, it’s durable and vibration-resistant.

An advanced BMS with Bluetooth, RS485, and CANbus provides intelligent protection and real-time monitoring. Certified to IEC62619, UN38.3, and compliant with AS/NZS 3001.2:2022 (RVs) and AS/NZS 3004.2:2014 (marine), this battery ensures safe, efficient, and long-lasting energy delivery.

FEATURES

High energy density, more usable energy in less space.

Lightweight and compact design.

Can safely use 100% of rated capacity.

Built to service higher loads without loss of capacity.

Flat discharge curve for longer run time and more efficient use of capacity.

Heavy-duty built-in Battery Protection System (BPS) with multiple safety features.

Explosion-proof nickel-plated steel prismatic case.

Flame-retardant electrolyte.

Integrated Bluetooth, RS485, and CANbus communication interfaces.

FAQ's

Q: Can this battery be used as a direct replacement for AGM or Gel batteries?

A: Yes, it is designed as an alternative replacement for most applications currently using a deep cycle Gel, AGM, or Flooded Lead Acid battery.

Q: Is the battery suitable for high-current applications?

A: Yes, with a maximum continuous discharge current of 200A and peak discharge current of 400A for 3 seconds, it is suitable for high-current applications.

Specifications

Product Code – AT-LFP-12-200-BTC-DV10

Chemistry – Lithium Iron Phosphate (LiFePO₄)

Nominal Voltage – 12.8V

Capacity – 200Ah / 2560Wh

Standard Charge Current – 40A

Maximum Charge Current – 200A

Maximum Continuous Discharge Current – 200A

Peak Discharge Current – 400A (for 3 seconds)

Cycle Life – >6000 cycles at 100% DoD

Operating Temperature – Charge: 0°C to 55°C; Discharge: -20°C to 55°C

Storage Temperature – -20°C to 40°C

Impedance – ≤20mΩ

Terminals – M8

IP Rating – IP50

Installation Information

Can be installed in various orientations, including on its side, without the risk of components coming loose or loss of usable capacity. Ensure all connections are clean and secure to maintain system integrity.

User Manual

Get a Quote - We can provide a quote on installing individual products such as a dual battery, lightbar or UHF or quote the installation of an entire build. Contact us via our contact form to discuss your needs. We'll provide a personalized quote for a complete system based on your preferences and budget, including installation services.



Please note we do not usually do installations on products purchased from other companies; exceptions may apply. It is best to contact us for further information.



We currently have one workshop located in Bayswater, Western Australia.

Warranty Information


Supplied with a 5-year manufacturer warranty covering defects in materials or workmanship.

Downloadable

PICKUP OR SHIPPING

Pickup: Available from Elevate Automotive (WA)

Shipping: Australia-wide shipping
