Home / Lighting / Driving & light bars

Britax Mini Relay 12V 40A N/O 5Pin Resistor

Britax

Mini Relay 12V 40A N/O 5Pin Resistor

R5-1240R

The Britax 12V 40A Mini Relay (R5-1240R) is a compact, heavy-duty electro-mechanical relay designed for automotive and industrial switching applications. Its 5-pin configuration and resistor protection ensure reliable performance in a variety of 12V vehicle electrical systems where stable current…

$9.90$11.00 Save $1.10

4 interest-free payments of $2.48 with
or pay over time with
We accept
Suitable for 12V automotive, marine, and industrial systems requiring reliable 40A switching capacity with resistor protection.

Shipping & collection

Worldwide shipping available*
In-store pickup
Professional installation available

*Shipping is calculated at checkout based on your location. Some products can't be delivered to every address.

The Britax 12V 40A Mini Relay (R5-1240R) is a compact, heavy-duty electro-mechanical relay designed for automotive and industrial switching applications. Its 5-pin configuration and resistor protection ensure reliable performance in a variety of 12V vehicle electrical systems where stable current control is required.

The Britax 12V 40A Mini Relay (R5-1240R) is a compact, heavy-duty electro-mechanical relay designed for automotive and industrial switching applications. Its 5-pin configuration and resistor protection ensure reliable performance in a variety of 12V vehicle electrical systems where stable current control is required.

  • 40A normally open contact for high-current circuits. Resistor protected for voltage spike suppression. Compact mini relay design for tight installations. Durable and reliable for automotive, marine, and industrial applications.


Voltage: 12V

Amperage: 40A (Normally Open)

Contacts: Normally Open

Terminals: 5 Pin

Protection: Resistor Protected

Relay Type: Mini Changeover Relay


Length: 26mm

Width: 26mm

Height: 25mm

Weight: 0.05kg

Everything this install needs

0 of 0 in the box


Designed for straightforward installation into standard 5-pin sockets. Ensure the relay is securely mounted and connections are properly made according to circuit requirements.

Suitable for 12V automotive, marine, and industrial systems requiring reliable 40A switching capacity with resistor protection.

Q: Is this relay resistor protected?

A: Yes, the Britax R5-1240R includes built-in resistor protection to suppress voltage spikes.

Q: Can this relay handle constant high current loads?

A: Yes, it is rated for continuous 40A operation on the normally open contact.
