KT Cable 300W Solar Blanket Kit with Charge Regulator

The innovative & powerful KT 300 Watt Portable Solar Blanket is ideal for 4WD, Camping & Recreational Outdoor Activities. Included with this kit, is a PWM 20Amp Solar Charge Regulator (IP65 Rated), Suitable for charging WET, Calcium, LifeP04 (Lithium Iron Phosphate), LTO (Lithium Titanium Oxide), Gel & AGM Batteries. Power Leads and Accessories included for easy connection to batteries & devices.

Designed as a convenient, light-weight, space-saving solar solution, the KT 300 Watt Solar Blanket features 3 x 5 (15 total) Monocrystalline Solar Cells which fold neatly into an easily transportable 390mm x 380mm x 140mm carry bag and weighing in at a light 8.85Kg.

Manufactured with a scratch-resistant matte coating for extra durability in Australian off-road conditions, The KT 300 Watt Solar Blanket features an innovative anti-theft tab which can be locked into the door of a vehicle, for peace of mind. The easy mounting loops allow the blanket to be mounted in various positions for ultimate solar harvest.

MAIN FEATURES

• One-Piece Easy-Fold Weather-Proof 300 Watt Solar Blanket

• Small, compact design for easy transportation and storage

• 50A Heavy Duty Connector wired to Solar Blanket for easy power connection

• Designed to charge LifePO4, LTO (Lithium Titanium Oxide), Gel, AGM, Conventional Lead-Acid (WET) and Calcium Batteries.

• 20A, 12V PWM Solar Charge Controller (IP65)

• 5M Power Lead with easy 50A connections to power

• 55cm Power Lead with Positive/Negative battery clamps & 20A in-line fuse

• Features securing tab to fix solar blanket to vehicle

• Blanket features loops along the edge to allow mounting in various positions

• Five accreditation certificates

INCLUDED IN THE KIT

1. 300W Solar Blanket which conveniently folds into a transportable bag

1. 55cm Power Leads with Positive/Negative Battery Clamps & 20Amp In-Line Fuse*

1. 20 Amp, 12V Solar Charge Controller with 180mm Cable Length*

1. 5M Power Lead with 50 Amp Connections*

*All Cable is 2.5mm Twin Core Cable

TECHNICAL SPECIFICATIONS

Type	Mono Crystalline
Max Power	300W
Max Power Voltage	18.8V
Max Power Current	15.98A
Open Circuit Voltage	22.15V
Short Circuit Current	16.42A
Dimensions Folded	390mm x 380mm x 5mm
Dimensions Unfolded	1140mm x 1970mm x 140mm
Test Conditions	AM1.5, 25°C, 1000W/m2
Fuse	20A
Battery Connections	Battery Clamps
Weight	8.85Kg
Solar Controller	20A, 12V
Accreditation Certificates



Solar Charge Controller

KT Solar Blanket features a built-in regulator to prevent your battery from being overcharged. Over-charging occurs when the charge voltage is unregulated. This can result in premature battery failure.
The regulator prevents your battery from being undercharged. In the solar energy field, battery undercharge always occurs, especially on some conventional Lead-Acid or Calcium batteries.

• Advanced MCU control Pulse Width Modulated (PWM) technology, high-efficiency operation.

• Suitable for LiFePO4, LTO (Lithium Titanium Oxide), Gel, AGM, Conventional Lead-Acid (WET) and Calcium Batteries.

• The unit provides an automatic equalisation feature for deeply drained conventional Lead-Acid or Calcium batteries, as well as providing a cycling automatic equalising feature every 28 days.

• Can be connected to the battery permanently to keep the battery fully charged using a process called floating. This means that the controller will stop charging when the battery is full and will automatically start charging the battery as required. This process will also reduce water loss and help prevent the battery from drying out.

• Protects your battery from discharge at night. Under low light or no light conditions, the Solar Panel voltage could be less than the battery voltage. The unit contains a special circuit which prevents current flowing back from the battery and into the solar panel.

• Coloured LED's to indicate the operational status and battery conditions.

• Digital LCD to directly display battery voltage, charging current, charging capacity (Amp-Hour), battery types, full charge and fault codes.

• Multi-charging protections against reverse polarity, short circuit, over temperature, over voltage, etc.

Warranty & Guarantees:

• 12 Month Warranty on Manufacture & Build

• 25 Year Efficiency Guarantee

• National Warranty Programme

IMPORTANT WARNING

It is recommended not to place your Solar Blanket over vehicle paint-work. Humidity can cause the blanket to stick to

paint-work. Solar Blankets are unlike tempered glass folding kits. They have a thick canvas material stitched in behind

the solar cells. Your KT Solar Blanket should be folded up and stored in a dry place at night whilst camping. Try to avoid

placing on wet grass during early morning sunlight and select a dry surface for the blanket to be placed. Unless

suspending or for windscreen application.
