Victron MultiPlus 24/5000/120-100 230V VE.Bus

SKU: PMP245021010

Pick Up Only - Please contact us via the Chatbox for Shipping options

$3,400.00
  • VEHICLE
  • INCLUDED
  • DIMENSIONS
  • Note from Manufacturer

Suitable for 4WDs, RVs, caravans, marine vessels, and off-grid systems.

  • Victron MultiPlus 24/5000/120-100 inverter/chargerunit
  • User manual

Victron MultiPlus 24/5000/120-100 230V VE.Bus

The Victron MultiPlus 24/5000/120-100 is a combined inverter and charger in one compact unit. It features a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, and multiple system integration capabilities. Ideal for off-grid, marine, and backup power applications, it ensures seamless power supply and efficient energy management.

 [{"variant_id":"50935072456977" , "metafield_value":""}]

Victron MultiPlus 24/5000/120-100 230V VE.Bus

$3,400.00
Description

The Victron MultiPlus 24/5000/120-100 is a combined inverter and charger in one compact unit. It features a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, and multiple system integration capabilities. Ideal for off-grid, marine, and backup power applications, it ensures seamless power supply and efficient energy management.

FEATURES
  • True sine wave inverter
  • Adaptive charging
  • Hybrid PowerAssist technology
  • Uninterrupted power supply (UPS) function
  • Parallel and three-phase operation
  • Remote monitoring and control via GX devices and
  • VRM portal
  • Compatible with lithium and lead-acid batteries
FAQ's

Q: Can multiple units be connected in parallel?A: Yes, up to 6 units can operate in parallel to achieve higher power output.

Q: Does it provide uninterrupted power supply (UPS) functionality?A: Yes, it automatically switches to inverter power in less than 20 milliseconds during grid failure.

Q: Can I monitor and control it remotely?A: Yes, with a GX device (e.g., Cerbo GX) and the free VRM portal/app.

Specifications

Model: PMP245021010

Input Voltage: 230V AC

Output Voltage: 230V AC

Continuous Output Power: 5000VA

Peak Power: 10000W

Charge Current (House Battery): 120A

Charge Current (Starter Battery): 4A

Transfer Switch Capacity: 100A

Frequency: 50Hz

Efficiency: Up to 93%

Dimensions (HxWxD): 240 x 328 x 444 mm

Weight: 30 kg

Ingress Protection: IP21

Installation Information

Victron MultiPlus 24/5000/120-100 230V VE.Bus


Warranty Information

5-year manufacturer warranty from Victron Energy.

PICKUP OR SHIPPING

Pick Up Only - Please contact us via the Chatbox for shipping options.
