Home / Lighting / Driving & light bars

Orion DC-DC Converters Non-isolated, High powerOrion DC-DC Converters Non-isolated, High power

Victron Energy

Victron Orion 24/12-80 DC-DC converter IP20

ORI241280020

The Victron Orion IP20 24/12-80A DC-DC Converter is a high-performance voltage converter designed to deliver stable and reliable 12V power from a 24V electrical system. Engineered for demanding automotive, marine, and off-grid applications, it provides a consistent 80A continuous output,…

$245.00

4 interest-free payments of $61.25 with
or finance your build with
Important note

The Victron Orion IP20 24/12-80A DC-DC converter is designed to provide reliable and efficient voltage conversion from 24V to 12V systems. Built for demanding automotive, marine, and off-grid applications, it delivers stable power output for sensitive electronics and high-load accessories. Engineered with Victron’s advanced conversion technology, it ensures consistent performance, efficiency, and long-term reliability in professional electrical installations.

We accept
Suitable for:

Shipping & collection

Worldwide shipping available*
In-store pickup
Professional installation available

*Shipping is calculated at checkout based on your location. Some products can't be delivered to every address.

The Victron Orion IP20 24/12-80A DC-DC Converter is a high-performance voltage converter designed to deliver stable and reliable 12V power from a 24V electrical system. Engineered for demanding automotive, marine, and off-grid applications, it provides a consistent 80A continuous output, making it suitable for powering high-load accessories or charging auxiliary battery systems.

Built with Victron’s proven conversion technology, the Orion IP20 features high efficiency operation, adjustable output voltage, and remote on/off capability for seamless integration into modern electrical systems. Its compact, aluminium IP20 enclosure is designed for protected installation environments where durability, thermal performance, and reliability are critical.

Ideal for 4WD builds, caravans, trucks, marine setups, and off-grid power systems, this unit ensures clean and stable power delivery even under varying load and input conditions.

  • Converts 24V DC to stable 12V DC output
  • High continuous output: up to 80A
  • Adjustable output voltage (10–15V range)
  • High-efficiency power conversion technology
  • Remote on/off control capability
  • Parallel operation supported for increased capacity
  • Compact aluminium IP20 enclosure
  • Designed for professional electrical installations
  • Stable output for sensitive electronics and accessories

Product: Victron Orion IP20 DC-DC Converter

Model: 24/12-80A

Part Number: 68352

Input Voltage: 18–35V DC

Output Voltage: 12V DC (adjustable 10–15V)

Output Current: 80A continuous

Efficiency: High-efficiency conversion

Control: Remote on/off terminal

Protection: Over-temperature, overload, short-circuit

Length195 mm
Width88 mm
Height65 mm (Approx. 19.5 cm x 8.8 cm x 6.5 cm)

Everything this install needs

0 of 0 in the box

This unit must be installed in a dry, well-ventilated location due to its IP20 rating.

Use appropriately rated cabling and fusing based on system load.

Remote on/off functionality allows integration with ignition or control circuits.

Professional installation is recommended to ensure safe and compliant wiring in 24V systems.

Suitable for:
24V commercial and heavy-duty vehicles
Trucks and fleet vehicles
4WD touring and expedition builds (24V systems)
Caravans and RV electrical systems
Marine and off-grid power systems

Q: Can this run sensitive electronics?
A: Yes, it provides stable regulated 12V output suitable for sensitive equipment.

Q: Is it suitable for 4WD use?
A: Yes, especially in 24V dual battery or auxiliary systems.

Q: Does it need ventilation?
A: Yes, due to IP20 rating it must be installed in a dry, ventilated area.

Q: Can units be combined?

A: Yes, multiple units can be used in parallel for higher output.
