Home / Lighting / Driving & light bars

Rocker Switch Mounting Panel — Middle (Carling 37×21mm)

Elevate Automotive

Rocker Switch Mounting Panel — Middle (Carling 37×21mm)

LV5127

Middle mounting panel for a Carling-style rocker switch (37.5×21mm cutout). Sits between side panels in a modular dash-switch row.

$8.50

4 interest-free payments of $2.13 with
or finance your build with
We accept
Universal fitmentDash-mount panel for Carling-style rocker switches

Shipping & collection

Worldwide shipping available*
In-store pickup
Professional installation available

*Shipping is calculated at checkout based on your location. Some products can't be delivered to every address.

A modular dash panel that holds a single Carling-style rocker switch in the middle of a multi-switch row. Sits between two side panels to build a clean multi-switch dash setup for 4WDs, caravan control panels, boat helms and canopy work-light rows. Takes the 37.5×21mm rocker cutout that Carling Contura II and most aftermarket 4WD switches share.

Moulded from durable ABS with a matte black finish. The dash cutout is 52×27.5mm and the panel sits flush against the dash face with the switch clip-mounting from behind. Panel width is roughly 30mm, height about 40mm. Connects side-by-side with the matching side panel by clipping into place.

Ships as the middle piece only. Pair it with two side panels to close the ends of the row, or add more middle pieces for longer rows. Rocker switches are sold separately, so pick the action (on/off, momentary, on-off-on) to match the load.

  • Middle position — for the centre of a multi-switch row
  • Carling cutout — 37.5×21mm fits standard rocker
  • 52×27.5mm dash hole — clean flush install
  • Modular design — pairs with side panels
  • Durable ABS — matte black dash-match finish
  • Universal fitment — dash, console, boat helm

Fitment

Switch cutout: 37.5 × 21 mm

Dash cutout: 52 × 27.5 mm

Position: Middle (expansion)

Physical

Material: ABS plastic

Finish: Matte black

Panel width: ~30 mm

Panel height: ~40 mm

Length: 80mm

Width: 40mm

Height: 120mm

Dash-mount panel for Carling-style rocker switches
12V and 24V DC systems (panel is passive; switch rating decides)
4WDs, caravans, boat helms, canopies, custom dash builds
Larger fascia-style OEM switches (Toyota, Nissan factory switches; use vendor-specific insert)

Q: What size switch does this fit?
The panel takes any rocker switch with a 37.5×21mm cutout. That is the Carling Contura II standard used by ARB, Narva, and most aftermarket 4WD rocker switches.

Q: What is a Carling switch, and how do I know if mine fits?
Carling is the US switch brand whose Contura II rocker became the industry standard for 4WD and marine aux switches. Any Carling-style switch measures 37.5×21mm across the mounting face. Measure your switch; if it matches, it fits this panel.

Q: Is this the whole panel or just one piece?
This is the middle section only. The middle piece sits between two side panels to build a multi-switch row. If you are mounting a single switch on its own, use a standalone rocker housing instead.

Q: How many switches can I run in a row?
As many as fit your dash. A basic three-switch row is one side, one middle, one side. Add another middle to make it four, another to make it five, and so on. Each middle adds one switch position.

Q: What size hole do I cut in the dash?
52×27.5mm for the panel opening. The rocker switch clips into the panel from behind, so you only cut the dash to fit the panel, not the switch.

Q: Are switches included?
No. The panel is sold on its own so you can pick the switch action (on/off, momentary, on-off-on, illuminated) that suits what you are wiring.

Q: Can I mix and match panels from different brands?
Only if the outside dimensions of the panel match the ones you already have. The 52×27.5mm dash cutout is roughly standard across most Carling-compatible housings, but panel widths can differ by a millimetre or two, which shows up as a visible seam. Stick to one brand for a clean row.

Q: Does it need any modification to fit?
No. Cut a 52×27.5mm rectangle in the dash, push the panel through from the front, and clip the switch in from behind. No screws needed if the dash face is 2 to 4mm thick.
