Victron Orion-Tr Smart 24/24-17A (400W) Isolated DC-DC Converter

SKU: ORI242441110
$293.55 $309.00
  • VEHICLE
  • INCLUDED
  • DIMENSIONS
  • Note from Manufacturer

Ideal for 4WDs, RVs, caravans, marine vessels, and off-grid systems.

  • Victron Orion-Tr Smart 24/24-17A (400W) DC-DC Charger
  • User manual

  • (HxWxD): 100 x 113 x 47 mm

The Victron Orion-Tr Smart 24/24-17A is a professional-grade, adaptive 3-stage DC-DC charger with built-in Bluetooth. Designed for dual battery systems in vehicles or boats, it utilizes the starter battery (via the alternator) to charge the service battery. It offers remote monitoring and configuration via the VictronConnect app and features an engine running detection mechanism.

 [{"variant_id":"50894870216977" , "metafield_value":""}]

Victron Orion-Tr Smart 24/24-17A (400W) Isolated DC-DC Converter

$293.55 $309.00
Description

The Victron Orion-Tr Smart 24/24-17A is a professional-grade, fully isolated DC-DC charger designed specifically for dual battery systems in vehicles, boats, and off-grid setups. Delivering up to 400W with a 17A charging current, this adaptive 3-stage charger efficiently uses the starter battery (via the alternator) to recharge the service battery, keeping your auxiliary systems powered and ready.

FEATURES


– Fully isolated DC-DC charger

– Adaptive 3-stage charging

– Bluetooth for easy monitoring and setup

– Engine running detection

– Remote on/off capability

– Compatible with lithium and lead-acid batteries

– Multiple units can be connected in parallel

– IP43 protection rating (when installed with terminals down)

FAQ's


Q: Is it compatible with lithium batteries?

A: Yes, it works with lithium and lead-acid.

Q: Can I monitor it remotely?

A: Yes, via Bluetooth and the VictronConnect app.

Q: Can I run multiple units in parallel?

A: Yes, for higher output.

Specifications
  • Model: ORI242441110
  • Input Voltage: 24V DC
  • Output Voltage: 24V DC
  • Charge Current: 17A
  • Output Power: 400W
  • Isolation: Fully isolated
  • Bluetooth: Built-in
  • Efficiency: Up to 95%
  • Engine Running Detection: Yes
  • Parallel Operation: Supported
  • Protection Rating: IP43 (terminals down)
  • Dimensions (HxWxD): 100 x 113 x 47 mm
  • Weight: 1.3 kg

    Victron Orion-Tr Smart 24/24-17A (400W) Isolated DC-DC Converter
Installation Information

Victron Orion-Tr Smart 24/24-17A (400W) Isolated DC-DC Converter

Warranty Information


5-year manufacturer warranty from Victron Energy.
