Canm8 Cannect Highbeam - 4 CAN Bus Module (Multi Output Interface)

SKU: CAN-LZR
$254.00
  • VEHICLE
  • INCLUDED
  • DIMENSIONS
  • Note from Manufacturer

Ford: Ranger (PX1–PX3), Everest
Volkswagen: Amarok (2H, 2nd Gen)
Toyota: LandCruiser 200/300 Series, Prado 150
Isuzu: D-MAX (RG), MU-X (RJ20)
Mitsubishi: Triton, Pajero, Pajero Sport
Nissan: Navara (D23), Patrol Y62
RAM: 1500, 2500
Jeep: Wrangler (JK, JL), Grand Cherokee
Land Rover: Defender (2020+), Discovery, Range Rover
Suzuki: Jimny, Vitara
Mazda: BT-50
Holden: Colorado (RG)
LDV: T60
Great Wall: Cannon (GWM Ute)

1 x CANM8 CANNECT HIGHBEAM-4 Module

1 x Mini Wiring Connector with labeled leads

1 x Instruction Sheet

(Relay and wiring harness sold separately)


Compact module with integrated mini wiring connector

Small footprint suitable for under-dash or engine bay mounting

Dimensions: Approx. 50 x 40 x 20 mm (excluding wiring)

The CANM8 CANNECT HIGHBEAM-4 simplifies the integration of auxiliary lighting systems with modern vehicles using CAN Bus wiring. Designed for reliability and fast installation, it ensures seamless operation of high beam-triggered accessories without interfering with vehicle electronics.

 [{"variant_id":"39552284786797" , "metafield_value":""}]

Canm8 Cannect Highbeam - 4 CAN Bus Module (Multi Output Interface)

$254.00
Description

The CANM8 CANNECT HIGHBEAM-4 is a 4-output CAN Bus interface designed to detect high beam activation and provide clean 12v outputs for driving light integration. Ideal for vehicles with CAN wiring, it simplifies the installation of auxiliary driving lights and includes additional outputs for ignition-on and side light signals.

This interface also supports Key-In detection, allowing the ignition-on output to stay live when the ignition is off but the key remains inserted (vehicle dependent).

FEATURES

CAN Bus detection of high beam, ignition, and side lights

3 independent 12v outputs (1A max each)

Supports Key-In functionality (vehicle dependent)

Plug-in connector for clean installation

LED diagnostics for setup confirmation

No need to splice factory headlight wiring

FAQ's

Q: Can I use this with LED or HID driving lights?
A: Yes, when connected via a relay—this module supplies a 12v trigger signal.

Q: Will this drain my battery?
A: No, the unit draws minimal power and only activates when CAN signals are present.

Q: Is professional installation required?
A: Not required, but recommended if you're not familiar with vehicle CAN wiring.

Specifications

Outputs: High Beam, Ignition On, Side Lights (12v, 1A max each)

Power Input: 12v via 5A fused permanent supply

CAN Connection: 2-wire (CAN HI / CAN LO)

Connector: Mini plug-in with labeled leads

Status LED: Multi-color, real-time diagnostics

Key-In Detection: Supported on compatible vehicles

Warranty: 12 months

Installation Information

Connect to CAN HI and CAN LO wires on the vehicle.

Power via fused permanent 12v supply.
Ground to vehicle chassis.

Outputs:

Brown: High Beam 12v (1A max)
Purple: Ignition On 12v (1A max)
Green: Side Lights 12v (1A max)

Plug-in connector for easy setup.
LED status indicator confirms CAN communication and vehicle recognition.

LED Indicators:

Flashing Red: Searching for CAN.
Solid Red: CAN received, vehicle not identified.
Solid Green: CAN received, vehicle recognised.
Flashing Green: Vehicle speed detected.

Warranty Information

Backed by a 12-month manufacturer warranty, covering defects in materials and workmanship. Warranty does not cover incorrect installation or misuse.
