Fuse Box with LED IndicatorsFuse Box with LED IndicatorsFuse Box with LED Indicators

Elevate Automotive

Fuse Box with LED Indicators

FBWL10

Positive-side fuse distribution block for standard blade (ATO/ATC) fuses, with an LED that lights when a fuse blows. Available in 4, 6 or 10-circuit versions for 12V and 24V DC accessory circuits. Not waterproof — indoor or protected mounting only.

VoltageUp to 32V DC
SealedNo
Fuse typeStandard blade

$55.00

4 interest-free payments of $13.75 with
or finance your build with
Type
We accept
Universal fitmentPositive-side fuse distribution block for 12V and 24V DC electrical systems.

Shipping & collection

Worldwide shipping available*
In-store pickup
Professional installation available

*Shipping is calculated at checkout based on your location. Some products can't be delivered to every address.

The Fuse Box with LED Indicators is a positive-side power distribution block for standard blade (ATO/ATC) fuses — one input splits into several independently-fused circuits from a single mounting point. Available in 4, 6 or 10-circuit configurations.

A red LED sits beside each fuse slot and lights up when that fuse has blown and the circuit downstream still has a path to ground — so a blown fuse is obvious at a glance instead of pulling each one to check. Good for distributing power to accessories like fridges, lighting, USB sockets and radios in vehicles, camper trailers, boats and 4WDs.

⚠ Do not: mount this outside or anywhere it can get wet — it is not sealed or waterproof. Mount inside a cabin, dash, canopy interior or a sealed enclosure.

Size guide

All three versions work the same way — pick by how many separately-fused circuits you need to run.

Version Circuits Good for
4-way 4 Small setups — fridge, lighting, USB socket
6-way 6 Mid-size 4WD or caravan builds
10-way 10 Full accessory setups with several circuits

You'll also need

Fuses aren't included — pick your amperages separately.

Standard Wedge Fuse Kit 120 Pieces

$34.95

  • LED Alerts — spot a blown fuse instantly, no guesswork
  • Standard Blade — common ATO/ATC fuses, easy to source
  • Multiple Sizes — 4, 6 or 10-way to match your circuit count
  • Clear Cover — snap-on lid, dust out, fuses visible

Fuse

Type: Standard blade

Also called: ATC / ATO / ATS

Voltage: 32V DC max

Circuits

Configurations: 4, 6 or 10-way

LED indicator: Per circuit

Housing

Body: Thermoplastic

Cover: Clear snap-on

Sealed: No — dry mount only

Positive-side fuse distribution block for 12V and 24V DC electrical systems.
12V and 24V DC systems (standard blade fuses rated to 32V DC)
Automotive, marine, caravan and 4WD accessory circuits
Not rated for 36V or 48V systems — use a 58V-rated fuse holder instead

Q: What does ATO/ATC blade fuse mean?
They're the same fuse under different names — the flat, colour-coded automotive fuses (red 10A, blue 15A, yellow 20A, clear 25A, green 30A). ATC (Automotive Thermoplastic Case) and ATO (Automotive Technology, Original) are interchangeable terms for the standard blade fuse this box takes.

Q: How does the LED blown-fuse indicator actually work?
Each LED sits in parallel across its fuse. While the fuse is intact there's almost no voltage across it, so the LED stays dark. Once the fuse blows, the full supply voltage appears across the open fuse and drives a tiny current through the LED instead — lighting it up, provided the downstream circuit still has a path to ground. It's a passive trick, not a powered sensor, so there's nothing to wire or configure.

Q: Does this include a negative or ground bus bar?
No. This block only distributes the positive/fused side. Each circuit still needs its own return path to a common ground or negative bus — budget for that separately if your setup doesn't already have one.

Q: Does it come with fuses?
No. Fuses are sold separately so you can pick the amperage each circuit actually needs — a USB socket and a fridge don't want the same fuse. We stock a 120-piece assorted standard blade kit with the common amperages.

Q: Can each circuit run a different fuse rating?
Yes. Every slot is independent — fit whatever amperage suits the load on that circuit, from a couple of amps for an LED strip up to 30A for a heavier accessory.

Q: Is this waterproof — can I mount it in the engine bay?
No. This is not sealed and isn't rated for engine bay, exposed or wet-location mounting. Mount it inside the cabin, under a dash, in a canopy interior or inside a sealed enclosure.

Q: Which version do I need — 4, 6 or 10-way?
Count the separate circuits you actually need to fuse, then add a couple of spare slots for whatever you add later. Most single-accessory setups (a fridge, or a lighting circuit) fit on a 4-way; a build with fridge, lighting, water pump and USB sockets is a 6-way; a fuller camper or off-grid build with many circuits suits the 10-way.

Q: Will mini or micro2 blade fuses fit this holder?
No. This box takes standard-size blade fuses only. Mini blade fuses (smaller, common on many modern Japanese and European vehicles) and micro2 fuses (smallest, tall and thin) are physically different sizes and won't seat in these slots.

Q: Can I use this on a 48V system?
No. Standard blade fuses are rated to 32V DC, which comfortably covers 12V and 24V systems but isn't rated to safely clear a fault on 48V. Use a 58V-rated fuse holder for 48V systems instead.

Q: Does the input wiring need to be rated for the total combined load?
Yes. Every circuit shares the one positive input stud, so the cable and fuse feeding that stud need to handle the sum of everything you'll run at once — not just the biggest single circuit.
