Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A
Orion XS DC-DC 12/12V 70A

Orion XS DC-DC 12/12V 70A

SKU: ORI121221040
$580.60
  • VEHICLE
  • INCLUDED
  • DIMENSIONS
  • Note from Manufacturer

Suitable for a wide range of vehicle electrical systems, including:

4WD and touring vehicles
LandCruiser models (70, 200, 300 Series)
Dual cab utes and vans
Vehicles with smart alternators

Victron Orion XS 12/12V 70A DC-DC Charger

Mounting bracket

Installation manual

Approx. 137mm x 123mm x 40mm

Lightweight, compact form factor for easy integration

The Victron Orion XS 12/12V 70A represents the next generation of DC-DC charging, offering improved efficiency, higher output, and full configurability in a compact form factor. Designed for modern vehicles and demanding electrical systems, it delivers reliable performance across a wide range of applications.

 [{"variant_id":"53668889231633" , "metafield_value":""}]

Orion XS DC-DC 12/12V 70A

$580.60
Description

The Victron Orion XS 12/12V 70A is a high-output DC-DC charger designed to deliver fast, reliable charging to your auxiliary battery system, even in modern vehicles with smart alternators. Compact, efficient, and built to Victron’s usual standard, it’s ideal for touring setups where performance and space both matter.

With up to 70A of charging output, the Orion XS is capable of supporting larger battery systems and higher power demands, making it well-suited for builds running fridges, lighting, and other 12V accessories.

FEATURES

70A high-output DC-DC charging for fast auxiliary battery charging

Compatible with smart alternators in modern vehicles

Fully programmable charging profiles via VictronConnect (Lithium, AGM, Gel, Lead-acid)

Built-in Bluetooth for monitoring and setup via smartphone

Adaptive 4-stage charging to optimise battery life

Engine running detection (no ignition wire required)

Advanced thermal management with automatic output derating

Parallel capability to increase total charging output if required

IP65-rated design (dust and water resistant)

Specifications

Input Voltage Range: 10 – 17V

Output Voltage: Adjustable via VictronConnect

Maximum Charge Current: 70A

Charging Algorithm: Adaptive 4-stage

Efficiency: Up to ~98%

Operating Temperature: -20°C to +60°C

Protection: Over-temperature, overload, short circuit

Installation Information

Designed for permanent installation in electric system

Can be mounted in tight or enclosed spaces due to compact design

Ensure adequate ventilation for optimal thermal performance

Suitable for charging auxiliary batteries from vehicle alternators

Professional installation recommended for best performance and safety

Warranty Information

5-year manufacturer warranty (Victron Energy)

PICKUP OR SHIPPING

Pickup available from our Perth workshop

Australia-wide shipping available

FAQ's

Q: What is the maximum charging output of the Orion XS 70A?
A: The Orion XS can deliver up to 70A of charging current, making it suitable for larger auxiliary battery systems and higher power demands.

Q: Can I monitor and adjust the charger settings?
A: Yes, the Orion XS has built-in Bluetooth, allowing you to monitor performance and adjust settings via the VictronConnect app.

Q: Is the charging profile adjustable?
A: Yes, charging parameters can be fully configured to suit lithium, AGM, gel, and lead-acid batteries.

Q: Does the Orion XS support parallel operation?
A: Yes, multiple units can be connected in parallel to increase total charging capacity for more demanding setups.

Q: Does the charger protect against overheating?
A: Yes, it features advanced thermal management and will automatically reduce output if temperatures get too high.

Q: Is the Orion XS suitable for modern vehicles?
A: Yes, it is designed to operate efficiently in modern vehicles, including those with smart alternators.

Q: Is the unit weather resistant?
A: Yes, the Orion XS has a sealed design and is rated to handle dust and water exposure in demanding environments.

Q: How efficient is the Orion XS charger?
A: The unit operates at very high efficiency (up to around 98%), helping reduce heat and maximise power transfer.
