Redarc BCDC Alpha25 12V 25A DC-DC charger with Bluetooth, front view

Redarc

BCDC Alpha25 — 12V 25A DC-DC Charger with Bluetooth

Name: Redarc BCDC Alpha25 — 12V 25A DC-DC Charger with Bluetooth
Brand: Redarc
SKU: BCDC12025B
Price: 799.00 AUD
Availability: InStock

BCDC12025B

25A DC-DC + MPPT charger with Bluetooth for a 12V auxiliary battery. Six battery profiles, Green Power Priority (solar first), IP67/69K sealed, 2-year Redarc warranty.

$799.00

4 interest-free payments of $199.75 with Afterpay

or finance your build with Allied Finance

We accept Visa Mastercard Amex Apple Pay PayPal Zip Afterpay Finance

12V systems onlyDC-DC + MPPT charger for a 12V auxiliary battery

Shipping & collection

Worldwide shipping available^*

In-store pickup

Professional installation available

*Shipping is calculated at checkout based on your location. Some products can't be delivered to every address.

25A DC-DC + MPPT SOLAR

Alpha series — premium in-cabin dual-input charger with Bluetooth.

REDARC APP CONTROL

Monitor charging and set the battery profile over Bluetooth from the Redarc app.

6 CHARGE PROFILES

AGM, gel, calcium, standard lead-acid, LiFePO4 and custom — any modern deep-cycle chemistry.

GREEN POWER PRIORITY

Solar takes precedence over the alternator when the panels are producing — saves fuel.

5 YEAR REDARC WARRANTY

Backed by 5 years direct from Redarc — the Alpha series carries the extended warranty. Repair or replacement in accordance with Redarc's warranty policy.

A 25A DC-DC charger that pulls from your vehicle's alternator and from solar at the same time, and sends the right profile to your 12V auxiliary battery. Keeps a fridge, lights, inverter and 12V accessories topped up on 4WDs, caravans, camper trailers, tourers and marine builds.

Bluetooth to the Redarc app runs live state-of-charge, battery profile selection and fault alerts. Six charge profiles cover AGM, gel, calcium, standard lead-acid, Heated Lithium and Standard Lithium. Green Power Priority runs the solar input first so the alternator does less work and the vehicle burns less fuel. 146 by 164 by 44mm chassis, 0.925kg, sealed to IP67/69K for engine bay or in-cabin install.

Output is 12V only. On late-model vehicles with stop-start or variable-voltage smart alternators, and on any build running more than one BCDC, hardwire an ignition trigger so chargers only run when the engine is running. Our workshop fits that trigger as part of the install.

What sets it apart

Dual input — alternator and solar wired at once, no switching.

Six charge profiles — AGM through Heated Lithium covered.

Green Power Priority — solar first, alternator second.

Bluetooth and app — state, profile and faults from your phone.

IP67/69K sealed — rated for engine bay or in-cabin install.

Made in Australia — designed, built and tested in Lonsdale, SA.

Running a 24V house system?

Redarc BCDC2420 — 24V 20A Under Bonnet DC-DC Charger with MPPT Solar Input

$799.00

25A dual input — alternator and solar wired at once
Six charge profiles — AGM through Heated Lithium
Green Power Priority — solar first, alternator second
Bluetooth app control — state, profile and faults from your phone
IP67/69K sealed — engine bay or in-cabin install
Flat start recovery — revives a dead crank battery in 15 minutes
Over-the-air updates — firmware through the Redarc app
Made in Australia — designed, built and tested in Lonsdale, SA

Electrical

Nominal output: 12V

Output current: 25A

Alternator input: 9-32V DC

Solar input: 9-48V DC

Charging

Charge profiles: 6

Priority: Solar first

MPPT: Yes

Build and protection

IP rating: IP67/69K

Operating temp: -40 to 85°C

Terminals: Screw

Interface: Bluetooth

Length: 146mm

Width: 164mm

Height: 44mm

Weight: 0.925kg

Mount the Alpha25 on a flat surface in the engine bay, under the dash, in a drawer system or on a battery tray. Keep clearance on each side for airflow. Terminals-down is preferred for drainage even with IP67/69K sealing.

Wire the alternator input, the solar input and the auxiliary battery output. Fuse the alternator input at the start battery and the output at the auxiliary battery. Minimum cable size scales with run length to keep voltage drop under 3 percent. See the Redarc install manual for the exact sizing chart.

Smart alternators and multi-charger setups. On late-model vehicles with stop-start or variable-voltage smart alternators, and on any build running more than one BCDC, hardwire an ignition trigger so chargers only run when the engine is running. Our workshop fits that trigger as standard on these vehicles.

Prefer a workshop install? Elevate is a Licensed Electrical Contractor (EC17073, Building & Energy WA). Bring the vehicle in for a full dual-battery install with the Alpha25 wired, fused and smart-alternator trigger set up.

DC-DC + MPPT charger for a 12V auxiliary battery

12V 4WDs, caravans, camper trailers, tourers and marine builds

Smart-alternator or stop-start vehicles (Elevate workshop wires the ignition trigger)

24V systems. Use the Redarc BCDC2420 instead

48V systems. Use a 48V-compatible DC-DC charger

Q: What does DC-DC charger actually mean?
A: A DC-DC charger takes 12V DC from the vehicle's alternator (or 12-48V from solar) and steps it to the right voltage and current profile for the auxiliary battery. Regulated charging without the losses of just linking the batteries in parallel.

Q: What does MPPT actually mean?
A: Maximum Power Point Tracking. The charger constantly adjusts the solar input voltage so you pull the most watts out of the panel at any time of day. Compared to a PWM controller, MPPT can harvest 20 to 30 percent more energy from the same panel.

Q: What does IP67/69K mean?
A: IP67 is dust-tight and survives 1 metre submersion for 30 minutes. IP69K adds resistance to high-pressure, high-temperature water jets (truck-wash grade). Together they mean the Alpha25 is sealed well enough for engine bay or in-cabin install.

Q: What makes the Alpha different from the Classic?
A: Bluetooth control through the Redarc app, over-the-air firmware updates and dedicated Heated Lithium and Standard Lithium profiles. The Classic BCDC1225D does the same core job (DC-DC + MPPT) without the Bluetooth or app features.

Q: Which battery chemistries does it support?
A: Six profiles. AGM, gel, calcium, standard lead-acid, Heated Lithium and Standard Lithium. Select the matching profile in the Redarc app so charge voltage and absorption times suit your bank.

Q: Can I run alternator and solar at the same time?
A: Yes. Both inputs wire in at once. Green Power Priority runs the solar side first and tops up from the alternator only when solar can't keep up, which saves fuel and alternator wear.

Q: Does it work with smart alternators?
A: Yes. On late-model vehicles with stop-start or variable-voltage smart alternators, and on any build running more than one BCDC, Elevate's workshop hardwires an ignition trigger so chargers only run when the engine is running.

Q: Can I install it in the engine bay?
A: Yes. The IP67/69K rating covers engine bay mounting. In-cabin and under-tray are also fine. Avoid direct exhaust heat and keep clearance for airflow.

Q: What can I see and set from the app?
A: State-of-charge, charge current, input voltage, selected battery profile, fault alerts and over-the-air firmware updates. Bluetooth connects to the Redarc app on iPhone or Android.

Q: What's the warranty?
A: 2 years from Redarc against manufacturing defects when installed per Redarc's instructions. The unit comes back to Redarc for repair or replacement.
